Product Details:

Place of Origin: China
Brand Name: Changgu
Certification: ISO 9001
Model Number: Nickel 200 Wire Mesh/Screen

Payment & Shipping Terms:

Minimum Order Quantity: 5 square meters
Packaging Details: Seal up, with plastic inside and wooden case or carton outside;
Delivery Time: within 7- 20 days after receiving the advance payment.
Payment Terms: L/C,T/T,Western Union, paypal
Get Best Price Contact Now

Detail Information

Product Description



NICKEL 200 (UNS N02200) WIRE MESH/SCREEN

The Nickel 200 Wire Mesh is commercially pure wrought Nickel 200 with good mechanical properties over a wide range of temperature. It has excellent resistance to many corrosives particularly hydroxides.
Nickel 200 Wire Mesh is weaved of nickel wire, the main characteristics of it is high temperature resisting (1000℃) acid resisting. It is a melting process which involves forging, rolling, annealing, drawing and weaving. Its weaving methods are twilled weaving and plain weaving. Nickel wire mesh offers excellent property of heat resistance, high temperature corrosion resistance, toughness and strength for the most demanding applications
To ensure the quality of our product, we can produce the product with raw materials from the international suppliers. Every batch of product can be tracked to the original raw material supplier. We co-operate with international suppliers like Allvac(ATI), Bohler, Carpenter, Dunkirk, Gloria, OttoKumpu, SMC, ThyssenKrupp VDM, Valbruna, etc.
Our talented team of experienced wire mesh technicians and engineers employ the latest technologies to produce quality wire mesh and its processed articles.

Characteristics of Nickel 200 Wire Mesh:
1. Highly resistant to various reducing chemicals
2. Excellent resistance to caustic alkalies
3. High electrical conductivity
4. Excellent corrosion resistance to distilled and natural waters
5. Resistance to neutral and alkaline salt solutions
6. Excellent resistance to dry fluorine
7. Widely used to handle caustic soda
8. Good thermal, electrical and magnetostrictive properties
9. Offers some resistance to hydrochloric and sulfuric acids at modest temperatures and concentrations.

     Mesh: 0.5-250mesh     Thickness: 0.1mm above.

Chemical Composition (%) of Nickel 200 Wire Mesh:

Ni
C
Mn
Cu
S
Si
Fe
Max

0.15
0.35
0.25
0.01
0.35
0.40
Min
99.0


Mechanical Properties of Nickel 200 Wire Mesh:
  Cold Worked Hot Worked
Ultimate Tensile ≥75KSi (≥515MPa) ≥55KSi (≥380MPa)
Yield Strength (0.2% OS) ≥50KSi (≥345MPa) ≥15KSi (≥105MPa)
Elong ≥15 ≥40

Product Description of Nickel 200 Wire Mesh:
       The product produced by us is of good quality and is priced reasonably
   Competitive price: The labour cost and cost on procuring the raw materials is low and hence the manufacturing cost is reasonable. We provide high facility in short producing cycle and have strong adaptive capacity in producing variation of products.
High quality assured: The work done by us has a good command of advanced technological process in the respect of smelting, rolling, drawing and heat treatment up to finished products. The chemical analysis department, the physical testing department and the quality control department all operate an all-round monitoring of our products from raw materials to final products.

    We can produce variety of products include strip, bar, plate, screen, wire, pipe, wire rod, mesh, netting and conveyor belt, wire and pipe and tube with high quality. We have the strong capacity of scientific research and development and can satisfy the customers' demands of the new products.

Applications of Nickel 200 Wire Mesh:
1.Manufacture and handling of sodium hydroxide, particularly at temperature above 300℃.
2. Production of viscose rayon. Manufacture of soap.
3. Analine hydrochloride production and in the chlorination of aliphatic hydrocarbons such as benzene, methane and ethane.
4. Manufacture of vinyl chloride monomer.
5. Reactors and vessels in which fluorine is generated and reacted with hydrocarbons.

Expanded Mesh
Perforated Mesh
Twill Weave mesh
Dutch Twill Weave Cloth
Dutch Weave Mesh
Reverse Dutch Weave Cloth
5-heddle Weave Mesh
Cross twill weave
Plain Weaving Mesh

Packing Process & Transportation of Nickel 200 Wire Mesh:
      Packaging: Seal up, with plastic inside and wooden case or carton outside; or according to the customer's requirements.
     Transportation:   By air: Beijing International Airport       OR   By sea: Trianjin Seaport

We provide products and services to meet your most specific requirements. We have experienced teams, effective managing system, advanced methods and producing equipment to offer good and reliable products. If you want more detailed information of this product or related problems, please contact with us, we will reply as soon as possible (general in 24 hours).
