314 Stainless Steel Wire Mesh

314 Stainless Steel Wire Mesh

314 Stainless Steel Wire Mesh

Product Details:

Place of Origin: China
Model Number: 314 Stainless Steel Wire Mesh

Payment & Shipping Terms:

Minimum Order Quantity: 1 roll
Packaging Details: Seal up, with plastic inside and wooden case or carton outside;
Delivery Time: within 7- 20 days after receiving the advance payment.
Payment Terms: L/C,T/T,Western Union, paypal
Contact Now
Detailed Product Description



Advantage:
1. Grade: SS 201, 202, 304, 314, 316, 304L, 316L, and etc.
2. Factory price
3. Fast delivery

Stainless steel wire:
1. Grade: SS 201, 202, 304, 314, 316, 321, 304L, 316L, etc.
Our biggest advantage is 314 qualitative material with a large backlog and shipping fast.

SS314 Material life:
Powder metallurgy: About 6 months
Thermal treatment furnace: Carburizing: 8 month. Don't carburizing: 10-12 months

2. Surface: Bright or dull
3. Condition: Soft and hard
4. Delivery: 15 days after receipt of the L/C or T. T
5. Package: By wooden case or rolls.
6. Payment: By L/C sight or T. T + copy of B/L.
7. Shipment: 15-20 days after receipt of the down payment or Irrevocable L/C sight.
8. Mill Test Certificate is supplied with shipment, Third Part Inspection is acceptable.
9. Trade terms: FOB SHANGHAI, or CIF import port.

10. Standard: ASME, ASTM, EN, BS, GB, DIN, JIS etc
Feel free to contact us if you have any other special requirements, we assure of our best attention all the time.

Dia.(mm) Tensile strenth(N/mm²) Dia.Tolerance(mm)
0.70-0.89 580-790 +/- 0.015
0.90-1.99 588-735 +/- 0.02
1.90-3.99 539-686 +/- 0.02
4.00-6.00 539-686 +/- 0.03




Type AISI    C Max %         Mn Max %  P Max%   S Max%  Si Max%  Cr%  Ni%  Mo%
201 0.15 5.50-7.50 0.06 0.03 1 16.000-18.00 0.5 -
202 0.15 7.50-10.00 0.06 0.03 1 17.00-19.00 3.-0-5.00 -
204CU 0.08 6.5-8.5 0.06 0.03 2 16.0-17.0 1.5-3.0 -
302 0.15 2 0.045 0.03 1 17.00-19.00 8.00-10.00 -
302HQ/ 0.03 2 0.045 0.02 1 17.00-19.00 9.00-10.00 -
304CU
304HC 0.04 0.80-1.70 0.04 0.015 0.3-0.6 18-19 8.5-9.5 -
303 0.07 2 0.045 0.25 Min 1 17-19 8.0-10.0 0.6
304 0.08 2 0.045 0.03 1 18.00-20.00 8.0-10.50 -
304L 0.03 2 0.045 0.03 1 18.00-20.00 8.00-12.00 -
310 S 0.055 1.5 0.04 0.005 0.7 25.0-28.0 19-22 -
314 0.25 2 0.045 0.03 1.50-3.00 23.00-26.00 19.00-22.00 -
316 0.06 2 0.045 0.03 1 16.00-18.00 10.00-14.00 2.00-3.00
316L 0.03 2 0.045 0.03 1 16.00-18.00 10.00-14.00 2.00-3.00
316Ti 0.08 2 0.045 0.03 0.75 16.00-18.00 10.00-14.00 2.00-3.00
347 0.08 2 0.045 0.03 1 17.00-19.00 9.00-13.00 -
321 0.06 2 0.045 0.01 .40-.60 17-19.00 9.4-9.6 -
ER308 0.08 2 0.045 0.03 1 17-19 9.5-13.0 -
ER308L 0.025 1.50/2.00 0.025 0.02 0.5 19.0/21.0 9.5/11.0 -
ER309 0.08 1.50/2.50 0.02 0.015 0.5 23.0/25.0 20.0/14.0 -
ER309L 0.025 1.50/2.50 0.02 0.015 0.5 23.0/25.0 12.0/14.0 -
ER316L 0.02 1.50/2.00 0.02 0.02 0.5 18.0/20.0 12.00-14.00 2.00-3.00
430L 0.03 1 0.04 0.03 1 16.00-18.00   -
434        0.08 1 0.04 0.03 1          16.00-18.00        -                0.90-1.40
