Stainless Steel Wire Mesh Plain Weave

Stainless Steel Wire Mesh Plain Weave

Stainless Steel Wire Mesh  Plain Weave

Product Details:

Place of Origin: China
Brand Name: Changgu
Certification: ISO 9001

Payment & Shipping Terms:

Minimum Order Quantity: 1 roll
Packaging Details: moist-proof paper/wooden crate/pallet
Delivery Time: within 15 days
Payment Terms: L/C,T/T,Western Union, paypal
Contact Now
Detailed Product Description
Material: Stainless Steel Wire Type: Wire Cloth
Application: Filters Weave Style: Plain Weave
Technique: Woven



 Stainless Steel Wire Mesh  Plain Weave Stainless Steel Wire Mesh
  Stainless Steel Wire Mesh  Plain Weave Plain Weave



Material: SS302; SS304; SS304L; SS316; SS316L
Features: Stainless Steel Wire Mesh is also named Stainless Steel Wire Cloth, it has the features of Acid resisting, alkali resisting, and heat resisting.
Application: Stainless Steel Wire Mesh is used for sifting and filtering in acid and alkali conditions. It is also used as Slurry Net in petroleum; Sifting Mesh and Screening Mesh in chemical and chemical fiber industry, Acid Washing Mesh in electric plating industry.

metal mesh-stainless steel wire meshmetal mesh-stainless steel wire meshmetal mesh-stainless steel wire mesh

Click for large pictureClick for large pictureClick for large picture

Stainless Steel Wire Mesh / Plain Weave
Specification Table

Mesh

/Inch

Wire Dia
(MM)



Mesh

/Inch

Wire Dia
(MM)

2Mesh

1.80mm

60Mesh

0.15mm

3Mesh

1.60mm

70Mesh

0.14mm

4Mesh

1.20mm

80Mesh

0.12mm

5Mesh

0.91mm

90Mesh

0.11mm

6Mesh

0.80mm

100Mesh

0.10mm

8Mesh

0.60mm

120Mesh

0.08mm

10Mesh

0.55mm

140Mesh

0.07mm

12Mesh

0.50mm

150Mesh

0.061mm

14Mesh

0.45mm

160Mesh

0.061mm

16Mesh

0.40mm

180Mesh

0.051mm

18Mesh

0.35mm

200Mesh

0.051mm

20Mesh

0.30mm

250Mesh

0.041mm

26Mesh

0.27mm

300Mesh

0.031mm

30Mesh

0.25mm

325Mesh

0.031mm

40Mesh

0.21mm

350Mesh

0.030mm

50Mesh

0.19mm

400Mesh

0.025mm

Width: up to 3.1M
Length: 30M/100Feet
Packing: moist-proof paper/wooden crate/pallet
