Home ProductsFeCrAl Mesh

H13YU4 0Cr13Al4 Mesh/Screen

H13YU4 0Cr13Al4 Mesh/Screen

H13YU4 0Cr13Al4 Mesh/Screen

Product Details:

Place of Origin: China
Model Number: H13YU4 0Cr13Al4 Mesh/Screen

Payment & Shipping Terms:

Packaging Details: Seal up, with plastic inside and wooden case or carton outside;
Payment Terms: L/C,T/T,Western Union, paypal
Contact Now
Detailed Product Description



H13YU4 0Cr13Al4 Mesh/Screen
Description
H13YU4 (0Cr13Al4)has received good feedback from foreign countries based on good quality and competitive price. As these alloys posses the characteristics of high resistance, low temperature coefficient of electric resistance, high operating temperature, good corrosion resistance under high temperature, especially under the atmosphere containing and/or sulfides, as well as the lower price, it is widely used in industrial electric furnaces, household electrical appliances and far infrared ray devices.

Chemical composition
The chemical composition of H13YU4,%
C
Si
Mn
Ni
S
P
Cr
Ti
Al
to 0.15
to 1
to 0.7
to 0.6
to 0.025
to 0.035
12 - 15
0.3
3.5 - 5.5

Properties:
Alloy
0Cr13Al4
H13YU4
Yield strength(MPa)
580-680
Elongation (%)
> 12
Density g/cm3
7.40
·Electrical resistivity (Ωmm2 / m).
1.25 ± 0.05
The highest temperature continuous operation (° C)
650
Melting point (° C)
1450
Thermal conductivity (kJ / m * h * ° C)
52.7
Coefficient of linear expansion (α × 10-6 / ° C)
4.15
