brass woven wire mesh(cloth)

brass woven wire mesh(cloth)

brass woven wire mesh(cloth)

Product Details:

Place of Origin: China
Brand Name: Changgu
Certification: ISO 9001

Payment & Shipping Terms:

Minimum Order Quantity: 5 square meters
Delivery Time: within 15 days
Payment Terms: T/T or L/C
Supply Ability: 1000 square meters per day
Contact Now
Detailed Product Description
Mesh Size: 1mesh/inch-200mesh/inch Material: Brass Wire
Application: Filter Type: Woven



Brass wire mesh is an alloy of copper and zinc, offers much better abrasion resistance, better corrosion resistance and lower electrical conductivity as compared with copper mesh.Brass wire mesh and phosphor bronze wire mesh are extensively used for sieving diversified pellet, powder, porcelain clay and glass, chinaware printing, filtering liquid and gas.
Material: Brass wire, phosphor bronze wire, or red copper wire
Application: Separation and sifting kinds pellet, grain,porcelain earth and glass, chinaware printing, filter liquid, etc.
Specifications:brass wire cloth 1mesh/inch-200mesh/inch; copper wire cloth 1mesh/inch-80mesh/inch; phosphor bronze wire cloth 1mesh-400mesh/inch
Width:0.914M, 1M, 1.5M
Length/roll:30M or 100ft
Weaving methods: Plain weave, twill weave or Dutch weave.


Brass wire mesh H65 H80
Mesh/Inch

Wire Diameter(mm)

Aperture(mm)

2 1.6 11.10
4 0.91 5.44
6 0.71 3.52
8 0.50 2.67
10 0.50 2.04
12 0.45 1.66
14 0.40 1.41
16 0.30 1.28
18 0.25 1.16
20 0.25 1.02
30 0.21 0.64
40 0.19 0.45
50 0.15 0.36
60 0.15 0.27
70 0.13 0.232
80 0.12 0.197
90 0.11 0.172
100 0.10 0.154
110 0.09 0.141
120 0.09 0.122
130 0.07 0.125
140 0.07 0.111
150 0.06 0.109
160 0.06 0.098
180 0.053 0.088
200 0.053 0.074
220 0.05 0.065
(width):0.60m-2.9m
