904L Stainless Steel Wire Mesh/Screen

904L Stainless Steel Wire Mesh/Screen

904L Stainless Steel Wire Mesh/Screen

Product Details:

Place of Origin: China
Model Number: 904L Stainless Steel Wire Mesh/Screen

Payment & Shipping Terms:

Minimum Order Quantity: 5 square meters
Packaging Details: Seal up, with plastic inside and wooden case or carton outside;
Delivery Time: within 7- 20 days after receiving the advance payment.
Payment Terms: L/C,T/T,Western Union, paypal
Contact Now
Detailed Product Description



904L Stainless Steel Wire/Screen
904L is a non-stabilized low carbon high alloy austenitic stainless steel. The addition of copper to this grade gives it greatly improved resistance to strong reducing acids, particularly sulphuric acid. It is also highly resistant to chloride attack - pitting / crevice corrosion and stress corrosion cracking.
This grade is non-magnetic in all conditions and has excellent weldability and formability. The austenitic structure also gives this grade excellent toughness, even down to cryogenic temperatures.
Mesh: 0.5-250 mesh/InchThickness: Min0.05mm

Grade specifications for 904L grade stainless steels.

Grade
UNS No
Old British
Euronorm
Swedish SS
BS
En
No
Name
904L
N08904
904S13
-
1.4539
X1NiCrMoCuN25-20-5
2562

Composition ranges for 904L grade of stainless steels.
Grade C Mn Si P S Cr Mo Ni Cu
904L min. - - - - - 19.0 4.0 23.0 1.0
  max. 0.020 2.00 1.00 0.045 0.035 23.0 5.0 28.0 2.0

Mechanical properties of 904L grade stainless steels.
Grade Tensile Strength (MPa) min Yield Strength 0.2% Proof (MPa) min Elongation (% in 50mm) min Hardness
Rockwell B (HR B) Brinell (HB)
904L 490 220 35 70-90 typical -
Rockwell Hardness value range is typical only; other values are specified limits.
Corrosion Resistance
(1)In most environments 904L has a corrosion performance intermediate between the standard austenitic grade 316L and the very highly alloyed 6% molybdenum and similar "super austenitic" grades.
(2)In aggressive nitric acid 904L has less resistance than molybdenum-free grades such as 304L and 310L.
(3)For maximum stress corrosion cracking resistance in critical environments the steel should be solution treated after cold work.
Heat Resistance
Good resistance to oxidation, but like other highly alloyed grades suffers from structural instability (precipitation of brittle phases such as sigma) at elevated temperatures. 904L should not be used above about 400°C.
Heat Treatment
Solution Treatment (Annealing) - heat to 1090-1175°C and cool rapidly. This grade cannot be hardened by thermal treatment.
Welding
904L can be successfully welded by all standard methods. Care needs to be taken as this grade solidifies fully austenitic, so is susceptible to hot cracking, particularly in constrained weldments. No pre-heat should be used and in most cases post weld heat treatment is also not required. AS 1554.6 pre-qualifies Grade 904L rods and electrodes for welding of 904L.
Applications
Typical applications include:
•         Processing plant for sulphuric, phosphoric and acetic acids
•         Pulp and paper processing
•         Components in gas scrubbing plants
•         Seawater cooling equipment
•         Oil refinery components
•         Wires in electrostatic precipitators
