INCOLOY 028 WIRE MESH / SCREEN
Incoloy 028 Wire Mesh is a highly alloyed austenitic stainless steel offering resistance to a variety of corrosive media. By virtue of its contents of chromium and molybdenum, Incoloy 028 Wire offers resistance to both oxidizing and reducing acids and salts. The presence of copper increases its resistance to sulfuric acid.
To ensure the quality of our product, we can produce the product with raw materials from the international suppliers. Every batch of product can be tracked to the original raw material supplier. We co-operate with international suppliers like Allvac(ATI), Bohler, Carpenter, Dunkirk, Gloria, OttoKumpu, SMC, ThyssenKrupp VDM, Valbruna, etc.
Available specifications:
Mesh: 0.5-250mesh, Thickness:0.05mm above
Chemical composition of Incoloy 028 Wire Mesh:
|
Alloy
|
Ni
|
Cr
|
Mo
|
Fe
|
C
|
Cu
|
Mn
|
P
|
S
|
|
Incoloy
028
|
30.0-34.0
|
26.0-28.0
|
3.0-4.0
|
Bal
|
0.03
max
|
0.6-1.4
|
2.5
max
|
0.03
max
|
0.03
max
|
Physical Properties of Incoloy 028 Wire Mesh:
|
Density,
|
0.292 lb/in3
|
|
8.0 g/cm3
|
|
Specific Heat
|
0.105 Btu/lb•°F
|
|
450J/kg•°C
|
|
Electrical Resistivity
.
|
594 ohm•circ mil/ft
|
|
0.99 Micro ohm m
|
|
Coefficient of Expansion
|
8.3 (77-212°F), 10-6 in/in•°F
|
|
15.0(25-100°C), ìm/m•°C
|
|
Young's Modulus
|
29.0*106 KSI
|
|
200 Gpa
|
Mechanical Properties of Incoloy 028 Wire Mesh:
|
Item |
Annealed |
Cold Worked |
|
Tensile Strength, KSI (Mpa) |
73(500) |
130(896) |
|
Yield Strength (0.2% Offset), KSI (Mpa) |
31(214) |
110(758) |
|
Elongation, % |
40 |
15 |
|
Hardness (HRB) |
80-90 |
33 max |
Applications:
1.Chemical and petrochemical processing industry.
2/Alloy tubes are cold worked to high strength levels for down hole service in moderately corrosive deep sour gas wells.
Mesh's Woven Method
|
Expanded Mesh
|
|
Perforated Mesh
|
|
Twill Weave mesh
|
|
Dutch Twill Weave Cloth
|
|
Dutch Weave Mesh
|
|
Reverse Dutch Weave Cloth
|
|
5-heddle Weave Mesh
|
|
Cross twill weave
|
|
Plain Weaving Mesh
|
Product Description: The product produced by us is of good quality and is priced reasonably.
Competitive price: The labour cost and cost on procuring the raw materials is low and hence the manufacturing cost is reasonable. We provide high facility in short producing cycle and have strong adaptive capacity in producing variation of products.
High quality assured: The work done by us has a good command of advanced technological process in the respect of smelting, rolling, drawing and heat treatment up to finished products. The chemical analysis department, the physical testing department and the quality control department all operate an all-round monitoring of our products from raw materials to final products.
Packing Process & Transportation:
Packaging: Seal up, with plastic inside and wooden case or carton outside; or according to the customer's requirements.
Transportation: By air: Beijing International Airport OR By sea: Trianjin Seaport
We provide our customers with excellent services. If you want more detailed information of this product or related problems, please contact with us, we will reply as soon as possible (general in 24 hours).
