Inconel X-750 Wire Mesh/ Screen
Product Details:
| Place of Origin: | China |
| Brand Name: | Changgu |
| Certification: | ISO 9001 |
| Model Number: | Inconel X-750 Wire Mesh/ Screen |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 square meters |
|---|---|
| Packaging Details: | Seal up, with plastic inside and wooden case or carton outside; |
| Delivery Time: | within 7- 20 days after receiving the advance payment. |
| Payment Terms: | L/C,T/T,Western Union, paypal |
|
Detail Information |
Product Description
INCONEL X-750 WIRE MESH / SCREEN
Inconel X-750 Wire Mesh/ Screen is a precipitation-hardenable alloy which has been used in applications such as high temperature structural members for gas turbines, jet engine parts, nuclear power plant applications, heat-treating fixtures, forming tools, and extrusion dies. The alloy is highly resistant to chemical corrosion and oxidation and has high stress-rupture strength and low creep rates under high stresses at temperatures up to 1500°F (816°C) after suitable heat treatment.
To ensure the quality of our product, we can produce the product with raw materials from the international suppliers. Every batch of product can be tracked to the original raw material supplier. We co-operate with international suppliers like Allvac(ATI), Bohler, Carpenter, Dunkirk, Gloria, OttoKumpu, SMC, ThyssenKrupp VDM, Valbruna, etc.
Available specifications of Inconel X-750 Wire Mesh:
Mesh: 0.5-250mesh, Thickness:0.05mm above
Chemical Composition(%) of Inconel X-750 Wire Mesh:
| Alloy | % | Ni | Cr | Fe | Nb | Ti | Co | C | Mn | Si | S | Cu | Al |
| Inconel X-750 | Min. | 70 | 14 | 5 | 0.7 | 2.25 | 0.4 | ||||||
| Max. | 17 | 9 | 1.2 | 2.75 | 1.0 | 0.08 | 1.0 | 0.5 | 0.01 | 0.5 | 1 |
Physical properties of Inconel X-750 Wire Mesh:
| Alloy | Density | Melting range |
| Inconel X-750 | 8.28 g/cm3 | 1393-1427 |
Mechanical properties in the room temperatureof Inconel X-750 Wire Mesh:
|
Alloy
|
Tensile strength
|
Yield strength
|
Elongation
|
Brinell hardness HB
|
|
Rm N/mm2
|
RP0.2 N/mm2
|
%
|
||
|
Solution treatment
|
1267
|
868
|
25
|
≤400
|
Applications :
1.high temperature structural members for gas turbines, jet engine parts,
2.nuclear power plant applications, heat-treating fixtures, forming tools, and extrusion dies.
Mesh's Woven Method
Mesh's Woven Method
|
Expanded Mesh
|
|
Perforated Mesh
|
|
Twill Weave mesh
|
|
Dutch Twill Weave Cloth
|
|
Dutch Weave Mesh
|
|
Reverse Dutch Weave Cloth
|
|
5-heddle Weave Mesh
|
|
Cross twill weave
|
|
Plain Weaving Mesh
|
Product Description: The product produced by us is of good quality and is priced reasonably.
Competitive price: The labour cost and cost on procuring the raw materials is low and hence the manufacturing cost is reasonable. We provide high facility in short producing cycle and have strong adaptive capacity in producing variation of products.
High quality assured: The work done by us has a good command of advanced technological process in the respect of smelting, rolling, drawing and heat treatment up to finished products. The chemical analysis department, the physical testing department and the quality control department all operate an all-round monitoring of our products from raw materials to final products.
Packing Process & Transportation:
Packaging: Seal up, with plastic inside and wooden case or carton outside; or according to the customer's requirements.
Transportation: By air: Beijing International Airport OR By sea: Trianjin Seaport
We provide our customers with excellent services. If you want more detailed information of this product or related problems, please contact with us, we will reply as soon as possible (general in 24 hours).
Want to Know more details about this product
