301 Stainless Steel Wire Mesh/Screen
Product Details:
| Place of Origin: | China |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 roll |
|---|---|
| Packaging Details: | Seal up, with plastic inside and wooden case or carton outside; |
| Delivery Time: | within 7- 20 days after receiving the advance payment. |
| Payment Terms: | L/C,T/T,Western Union, paypal |
|
Detail Information |
Product Description
Stainless Steel 301 wire mesh/screen is a commonly available austenitic stainless with good corrosion resistance and elevated carbon to allow for cold working to a variety of tempers.
Stainless Steel 301 wire mesh/screen Chemistry Data:
|
Carbon
|
0.15 max
|
|
Chromium
|
16 - 18
|
|
Iron
|
Balance
|
|
Manganese
|
2 max
|
|
Nickel
|
6 - 8
|
|
Phosphorus
|
0.045 max
|
|
Silicon
|
1 max
|
|
Sulphur
|
0.03 max
|
Stainless Steel 301 wire mesh/screen Physical Data:
|
Density (lb / cu. in.)
|
0.29
|
|
Specific Gravity
|
7.8
|
|
Specific Heat (Btu/lb/Deg F - [32-212 Deg F])
|
0.12
|
|
Electrical Resistivity (microhm-cm (at 68 Deg F))
|
432
|
|
Modulus of Elasticity Tension
|
28
|
Mechanical Properties
|
Grade 301 Temper ASTM A666
|
Tensile Strength (MPa) min.
|
Yield Strength 0.2% Proof (MPa) min.
|
Elongation (% in 50mm) (thick.>0.76mm) min.
|
Bend Test (thickness > 1.27mm)
|
|
|
Bend Angle (°)
|
Factor
|
||||
|
Annealed
|
515
|
205
|
40
|
-
|
-
|
|
1/16 Hard
|
620
|
310
|
40
|
180
|
1
|
|
1/8 Hard
|
690
|
380
|
40
|
180
|
1
|
|
1/4 Hard
|
860
|
515
|
25
|
90
|
2
|
|
1/2 Hard
|
1035
|
760
|
18
|
90
|
2
|
|
3/4 Hard
|
1205
|
930
|
12
|
90
|
3
|
|
Full Hard
|
1275
|
965
|
9
|
90
|
5
|
Stainless Steel 301 Applications
Automotive trim, kitchen equipment, hose clamps, wheel covers, aircraft components and a wide variety of industrial applications.
