Product Details:

Place of Origin: China
Brand Name: Jiechang
Model Number: Brass wire cloth

Payment & Shipping Terms:

Minimum Order Quantity: 1 square meter
Packaging Details: water proof paper
Payment Terms: L/C, T/T, Western Union
Get Best Price Contact Now

Detail Information

Material: Brass Wire/Phosphor Bronze Wire/Copper Wire Type: Weave Wire Mesh
Width: 1m 1.5m Color: Yellow
Length: 1-30m Or Customized Mesh Size: 1-250mesh
Packing: In Waterproof Paper And PVC Bag

Product Description

Brass wire mesh is a woven mesh made of brass wire.
Brass wire (65% copper, 35% zinc), therefore it is also called H65 brass mesh.


Material: H65 brass wire ( 65% Cu.35% Zn)

Mesh Count: 2-250

Weaving: Plain weave, twill weave

Roll width: 0.914m, 1.0m,1.2m Roll length: 30m



Features & Use:

  • Superior to copper abrasion resistance and tensile strength.
  • 60-70% copper plus 30-40% zinc.
  • Easily cut with hand tools.
  • It can be soldered with lead or silver solder.


And like copper wire mesh, brass wire mesh is soft and malleable. But its corrosion resistance is not as good as bronze.
As a wire mesh, the most commonly available brass woven wire mesh is referred to as “270 yellow brass” and has a chemical composition of approximately 65% copper, 35% zinc. “260 high brass”, which consists of 70% copper and 30% zinc is also popular in the mesh industry, particularly on custom manufactured items.


Main Material: 270 Yellow Brass (65% copper + 35% zinc), 260 High Brass (70% copper + 30% zinc)
Wire Diameter Range: 0.03-0.70mm.
Mesh Size Range: Plain Weave: 6– 160 mesh, Twill Weave: Up to 280 mesh, Dutch Weave: Can be customized as required.
Width Range: Usually, 0.914-3 m, can be cut according to customer requirements, the minimum is 3 mm.
Length Range: Usually 30 m, up to 150 m.
Mesh Type: Generally 30m/roll, various shapes can also be cut as required.


Brass wire mesh has good electrical conductivity and heat transfer properties, non-magnetic, anti-corrosion, low ductility, and anti-wear.Brass wire mesh is used for screen all kinds of particles, powders, china clay, glass, porcelain prints, filter liquids, gases.
