Gabion box, Garden Decoration, 2 x 1 x 1m, Environment-protection Gabion
Product Details:
| Place of Origin: | China |
| Brand Name: | Jiechang |
Payment & Shipping Terms:
| Price: | US$ 6 - 55 / Square Meter |
|---|---|
| Delivery Time: | 5 to 30 days according to the quantity |
| Payment Terms: | Western Union, L/C, T/T |
|
Detail Information |
Product Description
- Gabion box description:
- Gabions are double twisted hexagonal woven galvanized steel wire mesh baskets with a rectangular box shape
- Mounted within are diaphragms that form equal size compartments or cells
- Compartments or cells are filled with natural stone and the diaphragms minimize stone migration within the basket and providing even distribution of the stone fill throughout the basket even after structural movement
- Specification (standard):
- Gabion materials: low-carbon iron wire
- Gabion mesh shape: hexagonal
- Gabion mesh size: 60x80, 70x90, 80x100, 90x110, 100x120, 110x130, 120x150mm
- Gabion wire diameter:
- Main wire: 2.0-4mm
- Selvedge wire: 2.0-4.5mm
- Tie wire: 2.2mm(or C rings)
- Surface treatment power coated:
- Hot-dipped galvanized, heavy zinc coating, up to 290g/m2
- PVC coated mattresses and gabion baskets are also available with a 0.5mm nominal thickness PVC coating to enhance the resistance of the baskets to corrosion of the wire mesh
- This provides a overall increase in diameter of 1mm to all wires used in the manufacturing process
- Galfan, 95% zinc, 5% aluminum
- Features:
- Proven durability
- Design and installation support
- Environmentally-friendly
- Cost effective
- Aesthetically appealing
- Applications:
- Control and guide of water or flood
- Preventing of rock breaking
- Bridge protection
- Water and soil protection
- Seaport engineering
- Garden decoration
| Size | Notes | Tolerance | |||
| Length(m) | Width(m) | Height(m) | Unit | Cub(m ³ ) | Length ± 3% Width ± 5% Height ± 5% |
| 2.00 | 1.00 | 0.30 | 1 | 0.60 | |
| 3.00 | 1.00 | 0.30 | 2 | 0.90 | |
| 4.00 | 1.00 | 0.30 | 3 | 1.20 | |
| 2.00 | 1.00 | 0.50 | 1 | 1.00 | |
| 3.00 | 1.00 | 0.50 | 2 | 1.50 | |
| 4.00 | 1.00 | 0.50 | 3 | 2.00 | |
| 1.00 | 1.00 | 1.00 | 0 | 1.00 | |
| 1.50 | 1.00 | 1.00 | 0 | 1.50 | |
| 2.00 | 1.00 | 1.00 | 1 | 2.00 | |
| 3.00 | 1.00 | 1.00 | 2 | 3.00 | |
| 4.00 | 1.00 | 1.00 | 3 | 4.00 | |
