• Phosphorus Copper Wire Is Used in Sieving,Filtering of Industry for Resistant to Corrosion
Phosphorus Copper Wire Is Used in Sieving,Filtering of Industry for Resistant to Corrosion

Phosphorus Copper Wire Is Used in Sieving,Filtering of Industry for Resistant to Corrosion

Product Details:

Place of Origin: China
Brand Name: Changgu
Certification: ISO 9001

Payment & Shipping Terms:

Minimum Order Quantity: 5 square meters
Delivery Time: within 15 days
Payment Terms: T/T or L/C
Supply Ability: 1000 square meters per day
Get Best Price Contact Now

Detail Information
Mesh Size: 1mesh To 400mesh Material: Phosphor Bronze Wire
Application: Filter Type: Woven

Product Description



Phosphorus copper is also named green stannum copper.

Material: phosphorus copper wire. Phosphorus copper is an alloy of tin, phosphorus and copper. It's resistant to corrosion, wear, tear, etc. copper containing 85%-90%, tin: 5%-15%.

Weave: Plain weave, twill weave, etc.

Characteristic: The product is non-magnetic, resistant to corrosion, wear and tear etc., but it's not suitable for exposure to hydrochloric acid or strong oxidizing agents. Non magnetism, abrasion resistant, good ductilibility.

Uses: Usually used in sieving and filtering in pharmaceutical and food hygiene industry; sifting for porcelain clay, particles and powder; printing on the porcelain and glassware etc.

Specification Reference of Phosphor Bronze or Copper Wire Mesh (Cloth)

mesh wire diameter opening (mm)
SWG mm inch
6 22 0.711 0.028 3.522
8 23 0.610 0.024 2.565
10 25 0.508 0.020 2.032
12 26 0.457 0.018 1.660
14 27 0.417 0.016 1.397
16 29 0.345 0.014 1.243
18 30 0.315 0.012 1.096
20 30 0.315 0.0124 0.955
22 30 0.315 0.0124 0.840
24 30 0.315 0.0124 0.743
26 31 0.295 0.0116 0.682
28 31 0.295 0.0116 0.612
30 32 0.247 0.011 0.573
32 33 0.254 0.010 0.540
34 34 0.234 0.0092 0.513
36 34 0.234 0.0092 0.472
38 35 0.213 0.0084 0.455
40 36 0.193 0.0076 0.442
42 36 0.193 0.0076 0.412
44 37 0.173 0.0068 0.404
46 37 0.173 0.0068 0.379
48 37 0.173 0.0068 0.356
50 37 0.173 0.0068 0.335
60X50 36 0.0076 0.0076 -
60X50 37 0.0068 0.0068 -
60 37 0.0068 0.0068 0.250
70 39 0.132 0.0052 0.231
80 40 0.122 0.0048 0.196
90 41 0.112 0.0044 0.170
100 42 0.012 0.004 0.152
120X108 43 0.091 0.0036 -
120 44 0.081 0.3200 0.131
140 46 0.061 0.0024 0.120
150 46 0.061 0.0024 0.108
160 46 0.061 0.0024 0.098
180 47 0.051 0.002 0.090
200 47 0.051 0.002 0.076
250 48 0.041 0.0016 0.061
300 49 0.031 0.0012 0.054
325 49 0.031 0.0012 0.047
350 49 0.031 0.0012 0.042
400 49 0.031 0.0012 0.033
450 49 0.031 0.0012 0.029
500 50 0.025 0.0010 0.026
