Product Details:

Place of Origin: China
Brand Name: Jiechang
Certification: ISO 9001
Model Number: copper mesh

Payment & Shipping Terms:

Minimum Order Quantity: 1 square meter
Delivery Time: within 15 days
Payment Terms: T/T or L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 1000 square meters per day
Get Best Price Contact Now

Detail Information

Mesh Size: 2 - 220 Mesh/inch Type: Woven
Application: Filter,Screen,farady Cage Emf Electronic Shielding,Sieving Diversified Pellet,pest Proof Material: Brass Wire/Phosphor Bronze Wire/Copper Wire

Product Description



Copper mesh, also known as copper wire mesh or copper screen, is a plain square weave mesh woven by copper wire (copper is a soft and malleable material, and its chemical composition is 99.9% Cu), which has excellent thermal and electrical conductivity, and on-magnetic. So, copper mesh can be widely used as electromagnets interference and radio frequency interference shielding. It is also used as window insect screen or used for separation and filtration in many industries.

Because copper meshes have a long service life and as the sign of prestige and wealth, sometimes they are used in construction for decoration house facades, particularly for the walls and ceilings, as durable and reliable reinforcement material for plastering



Our copper wire mesh is available in various mesh counts and specific opening sizes as the following table to meet industrial requirements.

mesh/inch wire Dia.(mm) aperture (mm) mesh/inch wire Dia. (mm) aperture (mm) mesh/inch wire Dia. (mm) aperture (mm)
2 mesh 1.6 11.10 20 mesh 0.25 1.02 110 mesh 0.09 0.141
4 mesh 0.91 5.44 30 mesh 0.21 0.64 120 mesh 0.09 0.122
6 mesh 0.71 3.52 40 mesh 0.19 0.45 130 mesh 0.07 0.125
8 mesh 0.50 2.67 50 mesh 0.15 0.36 140 mesh 0.07 0.111
10 mesh 0.50 2.04 60 mesh 0.15 0.27 150 mesh 0.06 0.109
12 mesh 0.45 1.66 70 mesh 0.13 0.232 160 mesh 0.06 0.098
14 mesh 0.40 1.41 80 mesh 0.12 0.197 180 mesh 0.053 0.088
16 mesh 0.30 1.28 90 mesh 0.11 0.172 200 mesh 0.053 0.074
18 mesh 0.25 1.16 100 mesh 0.10 0.154 220 mesh 0.05 0.065
width:0.60m -1.8m



Our popular copper mesh size as below: wire diameter is between 0.3 mm -1.2 mm. The preferred wire diameter is 0.6 mm. The opening size of the mesh can be between 4 mm-6 mm. The preferred opening size of the mesh is 5 mm. Mesh shape is square. Copper bare wire mesh 300 × 300 mm spacing.

According to the wire specification, copper meshes can classified into coarse, medium and fine wire mesh. Coarse copper woven wire mesh includes 2 x 2 Mesh, 4 x 4 Mesh, 6 x 6 Mesh, 8 x 8 Mesh and 10 x 10 Mesh. Medium Copper Wire Mesh includes: 12 x 12 Mesh, 14 x 14 Mesh, 16 x 16 Mesh, 18 x 18 Mesh, 20 x 20 Mesh, 22 x 22 Mesh, 24 x 24 Mesh, 30 x 30 Mesh and 40 x 40 Mesh.Fine Copper Mesh includes: 50 x 50 Mesh, 60 x 60 Mesh, 80 x 80 Mesh and 100 x 100 Mesh.

According to materials copper mesh can be divided into three kinds namely brass wire mesh, purpose copper mesh and phosphor copper mesh.

Brass wire mesh (brass wire cloth)
Material: brass, we have 65 brass (the brass proportion is 65%, the zinc proportion is 35%), 80 brass (the brass proportion is 80%, the zinc proportion is 20%).
Specifications: 6 mesh/inch-160 mesh/inch, width 0.6 m-1.5 m, plain weave or twill weave.
Features: non-magnetic, wear- resistance and good ductility.
Usages: screening various granules, powder, porcelain clay and glass, chinaware printing, filtering liquid and gas.

Purple copper wire mesh (the alias of exhibition spacious mesh)
Material: purple copper wire (pure copper proportion 99.8%)
Specifications: 5 mesh-100 mesh, width 0.76 m-1.2 m, plain weave or twill weave.
Feature: non-magnetism and be able to bear the grind.
Usage: Purple copper wire mesh is widely used for filtrating electron beam and electron display screen.

Phosphor copper wire mesh (the alias of tin bronze mesh)
Material: phosphor copper wire (copper proportion 85%-90%, tin proportion is 5%-15%)
Specifications: 8 mesh-400 mesh/inch, width 0.6 m -1.5 m, plain weave or twill weave.
Features: non-magnetism and phosphor copper mesh can be able to bear the grind ache and alkali, good ductility.
Usages: screening various granules, powder, porcelain clay and glass, chinaware printing, filtering liquid and gas.
